| Type |
Belt drive turntable, fully automatic |
| Motor |
DC servo-controlled |
| Speeds |
33-1/3 RPM, 45 RPM |
| Turntable Platter |
Aluminum |
| Wow and Flutter |
< 0.25% (WTD) @ 3 kHz |
| Signal-to-Noise Ratio |
>50 dB (DIN-B) |
| Output Level |
Preamp "PHONO": 2.5 mV nominal at 1 kHz, 5 cm/sec Preamp "LINE": 150 mV nominal at 1 kHz, 5 cm/sec |
| Phono Pre-Amp Gain |
36 dB nominal, RIAA equalized |
| USB Function |
A/D, D/A: 16 bit, 44.1 kHz or 48 kHz selectable ; USB 2.0-compliant Windows 8.1 or above, or Mac OS X or above |
| Power Supply Requirements |
100 to 240 V, 50/60 Hz, 0.6 A Max. |
| Power Consumption |
1.5 W |
| Dimensions |
359.5 mm (14.15") W x 97.5 mm (3.84") H x 373.3 mm (14.70") D |
| Weight |
2.6 kg (5.73 lbs.) |
| Accessories Included |
Dust cover, Felt mat, Platter (with drive belt), 45 RPM adapter, RCA audio cable (approx. 1.2 m (3.9’)), USB cable (approx. 1.9 m (6.2')), AC adapter (approx. 1.5 m (4.9’)) |
| AC Adapter |
12 V, 0.5 A |
| Replacement Stylus |
ATN3600L |
| Communication System |
Bluetooth Version 5.0 |
| Maximum RF Output |
10 mW EIRP |
| Maximum Communication Range |
Line of sight - approx. 10 m (33') |
| Modulation Method |
FHSS |
| Compatible Bluetooth Profile |
A2DP |
